Panel Type
|
FAST IPS
|
|
Flat/Curve
|
Flat
|
|
Curved Ratio
|
N/A
|
|
Aspect Ratio
|
16:9
|
|
Screen Size
|
23.8"
|
|
Display Area（H*V）
|
527.04(H) × 296.46(V)
|
|
Panel Resolution
|
1920*1080
|
|
Refresh Rate
|
OC
|
165HZ
|
|
Overfrequency
|
180Hz
|
|
Backlight type
|
ELED
|
|
Brightness
|
Defaulted(TYP)
|
250 (±20）
|
|
Max(TYP)
|
300 (±20）
|
|
Default Color Temperature
|
7500K
|
|
Contrast Ratio
|
Static State
|
1000:1
|
|
Dynamic State
|
Millions
|
|
Pixels
|
16.7M
|
|
Color Gamut
(Coveraged)
|
sRGB
|
99%
|
|
HDR
|
HDR10
|
|
View Angle（H/V）
|
178°/178°
|
|
Response Time
|
OC （GTG）
|
1MS
|
|
OD Accelerate Response
|
N/A
|
|
I/O Prts（Standard）
|
1HDMI+1DP+Audio out
|
|
Port1
|
HDMI2.1
|
|
Port2
|
DP1.2
|
|
Port3
|
Audio out
|
|
Port4
|
DC 12V 3A
|
|
MPRT
|
Yes
|
|
Speaker
|
Yes (Only Supported on PC)
|
|
Power Input
|
DC 12V 3A
|
|
Power Supply
|
External power Adapter
|
|
Power Consumption
|
Input Power
|
36W
|
|
Stand-by Power Consumption（Max）
|
≦0.30W
|
|
Indicator Light Mode
|
Power on:Blue(LED)
|
|
Appearance Color
|
Black
|
|
RGB light / Gaming Light
|
NO
|
|
|
Unit W/stand
|
414*163*540mm
|
|
Unit W/O stand
|
322*39*540mm
|
|
Packing Size
|
610*100*395mm
|
|
|
Net Weight
|
2.9kg
|
|
Gross Weight
|
3.8kg
|
|
VESA Size(WxH)
|
VESA Demension
|
75*75 mm
|
|
Vesa Mount Method
|
Screw
|
|
Stand Functions
|
Angle （Forerake /Back-Lean）
|
Forerake ：5° Lean Back：15°
|
|
Up and Down（Vertical）
|
N/A
|
|
Swivel（L/R）
|
N/A
|
|
Pivot
|
N/A
|
|
OSD Key Control Mode
|
Rocker Button
|
|
OSD Manue Style
|
Blue and White
|
|
Language Menu
|
10 Countries Language(Defaut:English)
|
|
Main Functions
|
Color Temperature（Cold、Warm、User）
|
|
Low Blue Light Control
|
|
6 Contextual Models
|
|
DCR
|
|
Multiple-Language Menu
|
|
FPS/RTS Game Mode with 1 key-switch
|
|
GAME PLUS
|
|
FreeSync / Adaptive-Sync
|
|
HDR function
|
|
MPRT 1ms
|
|
Working Temperature
|
-20ºC~60ºC
|
|
Storage Temperature
|
0ºC~40ºC
|
|
Working Humidity
|
10~85%RH
|
|
Storage Humidity
|
5~90%(No Freezing under 40ºC ）
|
|
Altitudes
|
≤5000m
|
